McIntosh C70 2-Channel Vacuum Tube Preamplifier

ELECTRONIC SPECIFICATIONS

Number of Channels- 2

Total Harmonic Distortion- 0.08%

Frequency Response-

+0, -0.5dB from 20Hz to 20kHz

+0, -3dB from 15Hz to 100kHz

Maximum Volts Out (Balanced / Unbalanced)- 16V RMS / 8V RMS

Sensitivity High Level (Balanced / Unbalanced)- 900mV / 450mV

Sensitivity Phono (Moving Coil)- 0.45mV

Sensitivity Phono (Moving Magnet)- 4.5mV

Signal To Noise Ratio (High Level)- 100dB

Signal To Noise Ratio (Moving Coil)- 75dB

Signal To Noise Ratio (Moving Magnet)- 75dB

Voltage Gain (High Level)- 15dB

Voltage Gain (Moving Coil)- 60dB

Voltage Gain (Moving Magnet)- 40dB

Input Impedance (Balanced / Unbalanced)- 44K ohm, 22K ohm

CONNECTIVITY

Balanced Input- 2

Unbalanced Input- 3

Phono Input Moving Coil- 1 (adjustable)

Phono Input Moving Magnet- 1 (adjustable)

Balanced Variable Output- 2

Unbalanced Variable Output- 2

Headphone Output- 1/4" High Drive with Headphone Crossfeed Director (HXD®)

Unbalanced Analog Connector Type- Premium gold-plated solid brass

CONTROL

Tone Controls- Bass and Treble

Tone Bypass and Input Assign-

Tone Bypass: Yes

Input Assign: No

Power Control Output- 2 Main, 2 Switched

Rear Panel Data Port- 5

Rear Panel IR Sensor Input- Yes

GENERAL SPECIFICATIONS

Multi-Chassis or Single- Single, two-layer

Vacuum Tube or Solid State- Vacuum Tube: (5) 12AX7A and (1) 12AT7

Power Consumption (On)- 50 Watts

WEIGHTS & DIMENSIONS

Dimensions (W x H x D)- 44.45cm x 15.24cm x 45.72cm

Weight- 11.3kg

Shipping Weight- 18.8kg
