NAD M10 BluOS Streaming Amplifier

The NAD M10 represents a new kind of high-end audio system that is luxurious and smart, but very discreet. It can perform the same functions that once required a rack full of components and in many ways is superior. The elegant form factor takes up very little space and can even be hidden away, but the beautiful design and colourful display will encourage you to place the M10 front and center.

BluOS Streaming Amplifier

HybridDigital nCore Amplifier

Continuous Power: 100W into 8/4 Ohms

Dynamic Power: 160W into 8 Ohms 300W into 4 Ohms

32-BIT/384kHz ESS Sabre DAC

1GHz ARM® CORTEX A9 Processor

Dirac Live Room Correction*

Color LCD display

Supports Amazon Alexa and Google Assistant Voice Control Skills

AirPlay 2 Integration

Supports Siri Voice Assistant via AirPlay 2

Two-way Qualcomm aptX HD Bluetooth

NFC Bluetooth pairing for compatible smart devices

BluOS multi-room compatible

Gigabit Ethernet

HDMI eARC, USB Type A Input

Stereo Line Inputs, Coax/Optical Inputs

Preamp Output, Dual Mono Subwoofer Outputs

IR Input, 12V Trigger Out

Apps for iOS, Android, Mac OS, Windows,

Crestron, Control4, RTI, URC, Elan, Lutron,

iPort

Wide variety of premium music services

supported in App, including Amazon, Spotify,

Tidal, TuneIn, Napster, Deezer, Qobuz and

many others

AMPLIFIER SECTION

LINE INPUT, SPEAKER OUT

Continuous output power into 8 ohms and 4 ohms

>100W (ref. 20 Hz-20 kHz at rated THD, both channels driven)

THD (20 Hz – 20 kHz)

<0.03 % (250 mW to 100 W, 8 ohms and 4 ohms)

Signal-to-Noise Ratio

>90 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)

Clipping power

>130 W (at 1 kHz 8 ohms 0.1 % THD)

>230 W (at 1 kHz 4 ohms 0.1 % THD)

IHF dynamic power

8 ohms: 160 W

4 ohms: 300 W

Damping factor

>190 (ref. 8 ohms, 20Hz to 6.5kHz)

Frequency response

±0.6 dB (20 Hz – 20 kHz)

Tone controls

Treble: ±6.0 dB at 20 kHz

Bass: ±6.0dB at 60 Hz

Channel separation

>75 dB (1 kHz)

>70 dB (10 kHz)

Input sensitivity (for 100 W in 8 ohms)

Line In: 1.0 V

Digital In: -6.2 %FS

Standby power

0.5W

DAC SECTION

Supported audio file formats

MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS

Hi-Resolution audio formats

MQA, FLAC, WAV, AIFF, Supports converted DSD playback via the BluOS desktop app (only)

Sampling rate

up to 32 bit/192 kHz PCM

Bit depths

16 – 24

BluOS SECTION

Supported operating systems

Plays music from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and Mac OS X versions

User interface mobile operating system BluOS

BluOS – Free Android and iOS App available online at Google Play and Apple App store

Supported cloud services*

Amazon Alexa, Amazon Music, Spotify, TIDAL, Deezer, Qobuz, HDTracks, HighResAudio, Murfie, JUKE, Napster, Slacker Radio, KKBox, Bugs

Free internet radio*

TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise

Bluetooth quality

Bluetooth aptX HD built-in

Bluetooth connectivity

Two-Way (Receive and Headphone modes)

Network connectivity

Gigabit Ethernet RJ45, Wi-Fi 5

DIMENSION AND WEIGHT

Gross dimensions (W x H x D)**

215 x 100 x 260 mm

8 1/2 x 3 15/16 x 10 1/4 inches

Shipping weight

5 kg (11 lbs)
