Lyra Atlas SL Lambda Moving Coil Phono Cartridge

This is a special, built-to-order, version of Atlas for expert users with very high-gain, extra low noise phono stages, or alternatively a step-up transformer designed for phono cartridges of 2 – 3 ohms or less.

Most users (and phono stages) will benefit from the regular Atlas with much higher output and considerably more energy; resulting in a much better signal-to-noise ratio. If you are in doubt about which version of Atlas that will work best in your system, please go with the regular Atlas.

The Atlas SL may provide extra pure and pristine sound from an audio system that is optimized for a low-impedance, low-output cartridge. However, this may be accompanied with a lesser level of energy and power.

Lyra nevertheless has decided to offer SL models, as built-to-order at a 10% surcharge, for those who are confident that they can extract the benefits from such a low-output MC phono cartridge.

Specification:

• Designer:Jonathan Carr
• Builder:Yoshinori Mishima
• Type:Medium weight, medium compliance, low-impedance moving coil cartridge
• Stylus:Lyra-designed long-footprint variable-radius line-contact nude diamond (3μm×70μm), slot-mounted
• Cantilever system:Diamond-coated solid boron rod with short one-point wire suspension, directly mounted into cartridge body via high pressure knife-edge system
• Coils:single layer, 6 N high-purity copper, chemically-purified high-purity iron cross-shaped former, 1.52 ohm self-impedance, 1.9μH inductance
• Output voltage:0.25mV@5 cm/sec., zero to peak, 45 degrees (CBS test record, other test records may alter results)
• Frequency range:10 Hz〜50 kHz
• Channel separation:35 dB or better at 1 kHz
• Compliance:Approx. 12×10 cm/dyne at 100 Hz
• Vertical tracking angle:20 degrees
• Cartridge body:One-piece machining from solid titanium billet, with reduced-surface higher-pressure headshell contact area, predominately non-parallel and asymmetrical shaping, phase-interference resonance-controlling mechanism, and body threaded directly for mounting screws
• Cartridge mounting screws:2.6 mm 0.45 pitch JIS standard
• Cartridge weight (without stylus cover):11.6 g
• Distance from mounting holes to stylus tip:9.5 mm
• Recommended tracking force:1.65〜1.75 g (1.72 g recommended)
• Recommended load directly into MC phono input:Determine by listeing
• Recommended load via step-up transformer:1〜10 ohm (connect step-up transformer’s output to 10kohm〜47kohm MM-level RIAA input, preferably via short, low capacitance cable)
• Recommended tonearm:High-quality pivoted or linear (tangential) tonearm with rigid bearing(s), adjustable anti-skating force, preferably VTA adjustment
