Luxman DA-250 DAC

$900.00

Brand New Luxman DA-250 DAC with International Warranty

Description
Product Details

Luxman DA-250 DAC

Luxman’s DA-250 is a Class A Preamplifer, Class A Headphone Amplifier and a USB capable Digital Audio Converter packaged in a slim & compact B4 form factor. It delivers a wonderfully musical rich tone that will provide countless hours of fatigue-free listening enjoyment.

USB input is compatible up to 192 kHz/32bit PCM data and DSD data (2.8MHz and 5.6MHz).

S/PDIF input handles up to 192 kHz/24bit PCM signals.

In addition to USB input, the DA-250 has a coaxial input and two optical (Toslink) inputs to enable connection with a CD player and / or DVR, satellite radio etc.

The Texas Instruments PCM1795 was selected for the DAC, which contains a 32 bit digital filter, digital signals are up-converted internally to 352.8k or 384kHz/32 bit.

Two different kinds of tone filter setting are provided and switchable to your taste (32bit digital filter for PCM and analog FIR filter for DSD).

Specifications:

Format	2-channel D/A converter
Supported sampling frequencies	USB input (PCM) : 32k, 44.1k, 48k, 88.2k 96k, 176.4k, 192k(16, 24, 32bits) USB input (DSD) : 2.82M, 5.64MHz (1bit) COAX/OPT input : 32k, 44.1k, 48k, 88.2k 96k, 176.4k, 192kHz (16, 20, 24bits) MC HIGH: 0.37mV, MC LOW: 0.12mV
Digital input	USB x 1, COAX x 1, OPT x 2
Digital output	COAX x 1, OPT x 1
Analog input	Unbalance x 1
Analog output	Unbalance x 1, Balance x 1, Headphone x 1
Line output voltage/imipedance	Unbalance : 2.5V/300Ω, Balance : 2.5V/600Ω

Headphone output	130mW + 130mW(600Ω) 400mW + 400mW(32Ω), 200mW + 200mW(16Ω)
Frequency response	2Hz to 50kHz (+0, -3.0dB)
Total harmonic distortion	0.001%
S/N ratio (IHF-A)	118dB
Power supply	230V~(50Hz) / 115V~(60Hz)
Power consumption	20W
Dimensions	364(W) x 81(H) x 279(D) mm front side knob of 14mm and rear side terminal of 8mm included in depth
Net weight	5.4kg(main unit)
Accessories	Remote control (RD-24) Power cable
